ADVANCED OPERATION
15
Note: Do not disconnect the power of your DVR while the upgrade process is in progress, or the DVR
functions may not work normally or be unable to use.
8) AUTO KEYLOCK (SEC)
Set the time-out in second after which the key lock function is activated (NEVER / 30 / 60 / 120).
9) LANGUAGE
Select the language of the OSD.
10) VIDEO FORMAT
Here shows the information of the DVR video format (NTSC / PAL).
11) VERSION
Here shows the firmware version information.
5.7. NETWORK (Selected models only)
In this menu list, you can set up the network.
Move to “NETWORK”, and press “ENTER” button to enter the submenu. The submenu items are described below.
5.7.1. STATIC
1) NETWORK TYPE
Select the network type as STATIC and set all the information needed in the DVR.
2) NETWORK INFORMATION (IP / GATEWAY / NETMASK)
Key in all the network information obtained from your ISP (Internet Service Provider).
3) DNS (PRIMARY DNS / SECONDARY DNS)
Key in the IP address of the domain name server obtained from your ISP (Internet Service Provider).
4) PORT
The valid number ranges from 1 to 9999. The default value is 80. Typically, the TCP port used by HTTP is 80.
However in some cases, it is better to change this port number for added flexibility or security.
See the example below:
STATIC
NETWORK TYPE STATIC
IP 192 . 168 . 001 . 012
GATEWAY 192 . 168 . 001 . 254
NETMASK 255 . 255 . 252 . 000
PRIMARY DNS 168 . 095 . 001 . 001
SECONDARY DNS 139 . 175 . 055 . 244
PORT 0080
PLEASE CONSULT YOUR INSTALLER FOR ADVANCE SETTING
uv SELECT s BACK t NEXT ENTER
5.7.2. PPPOE
1) NETWORK TYPE
Select the network type as PPPOE.
