Avtech Room Alert 32S - Room Alert 32 S Package Contents; The Room Alert 32 S ID Box; Front; Back

AVTECH Software, Inc. Page 3 AVTECH.com
Room Alert 32S (RA32S-DAP-RAS)
Room Alert 32S Hardware
Front
9
2
5
10
6
Power
Port
Internal Sensors
• Temperature
• Humidity
• Power
• Battery Back-up
Back
Battery
Back-up
On / O
Button
Switch
Sensor
Ports
(16)
Reset
Button
Relay
Output
Ports
(2)
8
7
11
3
1
4
Power
LED
Digital
Sensor
Ports
(8)
Ethernet
Port
Alarm
LEDs
Light Tower &
Relay Adapter
Ports
(2)
Analog
Input
Ports
(2)
(PoE enabled)
