axing OTX 1310-10 User Manual

Operation Instructions | OTX 1310-10 | Optical Transmitter
14 2017-10-03 | Technical improvements, changes in design, printing- and other errors expected.
6. Specification
6.1. Optical characteristics
Parameter Unit Value
Working Wavelength nm 1290~1330
Output Power mW 10
Optical Fiber Type -- SM
Optical Connector -- SC/APC
6.2. RF characteristics
Parameter Unit Value
Frequency Range MHz 47…1002
RF Input Return Loss dBm ≥16
RF Input Level dBμV 75~85
Flatness dB ±0.75
CNR1 dB >50
CSO1 dBC ≤-60
CTB1 dBC ≤-65
Testing condition: OIM=3.5%, optical input power @-1dBm, 98chs signal output, above 550MHz at -10dB
offset.
6.3. Other characteristics
Parameter Unit Value
Operating Voltage V
90～260, 50Hz
Power Consumption W ≤30
Operating Temperature °C 0~50
Dimension（L*W*H）
mm 484*370*44
Weight Kg <3.5

axing OTX 1310-10 Specifications

General

Brand	axing
Model	OTX 1310-10
Category	Transmitter
Language	English
