6.FordetectiontypeIncrease:Entertheincreaserate(F)indegreespersecondsintheIncreaserateelds.
-TheY-axis:thedegreesinCelsiusorFahrenheit
-TheX-axis:theincreasetimeinseconds
7.ClickSavetosaveyoursettingsorcontinuetotheAdvancedSettingssectiontosetadditionaldetectionconditions.
AdvancedSettings
1.Inatemperaturedetectionzone:SelectAdvancedSettingstoshowadditionaldetectionsettings.
2.Enteranemissivityvalue(0.50–1.00).intheEmissivityeld.Differentmaterialshavedifferentemissivitylevels.See
MaterialEmissivityTableonpage31.
3.SelectMaximumtemperatureinthezoneorMinimumtemperatureinthezoneasthebasefortemperaturedetection:
-Maximumtemperatureinzone(C):Thetemperaturedetection(Above/Below/Increase)willbebasedon
themaximumtemperatureinthezone.
-Minimumtemperatureinzone(C):Thetemperaturedetection(Above/Below/Increase)willbebasedon
theminimumtemperatureinthezone.
