AXIS 2100 Installation Guide - English Page 1 of 5
Installing Your Camera on a Network
Follow the guide below to quickly install your AXIS 2100 on an Ethernet network:
Important!
❶ Note the Serial number on the underside of the unit. You need to know this to set the IP address:
❷ Using an appropriate method for your operating system, assign your product with a unique IP
Address from a computer on your network, as follows:
Note: In some Unix systems, the arp command can be located in a directory that is not on the
command path; e.g: /usr/sbin/arp
You w i l l n ow se e ‘Request timed out ...’ messages repeatedly returned within the DOS
window.
For details on installing the AXIS 2100 to a modem, see page 2.
Serial number same as
00408c100086 =
Ethernet number; e.g.
00-40-8c-10-00-86
Windows 95, 98, NT and 2000 only - Start a DOS window and type
these commands:
Syntax:
arp -s <Server IP address> <Ethernet address> <my PC IP address>
ping -t <Server IP address>
Example:
arp -s 172.21.1.200 00-40-8c-10-00-86 172.21.1.193
ping -t 172.21.1.200
UNIX only - Type these commands in your command
line:
Syntax:
arp -s <IP address> <Ethernet address> temp
ping <IP address>
Example:
arp -s 172.21.1.200 00:40:8c:10:00:86 temp
ping 172.21.1.200
❸ Connect an Ethernet cable to your AXIS
2100 and attach it to the network.
❹ Connect the external Power Supply to the
unit and connect it to your main power supply.
RJ-45 connector
Network connector
Network Indicator
Power Indicator
Power Supply
Connector
❻ Exit Ping. The installation is now complete, and you are ready
to access the AXIS 2100 from your Web browser, as described in
the next section.
❺ Approximately 10-15 seconds after connecting the power supply, the
message ‘Reply from 172.21.1.200...’ - or similar, is returned within the
DOS window. Ensure that the Power Indicator is permanently lit and that
the Network Indicator flashes intermittently.
To Next Page
