AXIS 2100 Installation Guide - English Page 4 of 5
Refining the Dial-Up Networking Properties...
Having created the Dial-Up connection for your AXIS 2100, follow the steps below to refine the
connection properties:
Initiating the Dial-Up Connection
Important!
Please ensure that the Null Modem Cable is correctly installed and that the relative connection properties are cor-
rectly configured before initiating a Dial-Up connection. Step-by-step instructions on how to do this are provided
on the preceding pages of this section.
❷ Click the Server Types tab. From the
drop-down list, select PPP as the Type
of Dial-Up Server.
❶From the Dial-Up Networking dialog, right click the dedicated
Dial-Up connection previously created for your AXIS 2100 (Axis-
Camera was the connection created used in this and previous
examples). Select Properties.
❸ In the Advanced options field, check
Enable software compression. All other
checkboxes should remain unchecked.
❹ In the Allowed network protocols field,
check the TCP/IP checkbox. NetBEUI and IPX/
SPX checkboxes should remain unchecked.
❻ Check the Use IP header compres-
sion and Use default gateway on a
remote network checkboxes. Click OK.
❼ Click the Scripting tab and ensure that the Start
terminal screen minimized checkbox is checked. Click OK
to exit Dial-Up Networking Properties.
❺ Click TCP/IP settings and then check
the Server assigned IP address, and Server
assigned name server addresses radio
buttons.
❷ Double-click the Dial-Up connection
icon previously created for your AXIS
2100 (AxisCamera in this and previous
examples).
❶ Double-click My Computer and then
double-click the Dial-Up Networking
icon.
❸ Enter a Username and Pass-
word, using the default root and
pass respectively.
❹ Click Connect to initiate the
Dial-Up connection.
To Next Page
