AXIS 211W Installation Guide
Hardware overview
Dimensions
HxWxD = 38 x 88 x1
80mm (1.5" x 3.5" x 7")
Weight =260g (0.57 lb) (without
antenna)
Network indicator LED
Netw
ork
connector
Power indicator LED
Status indicator LED and
Internal microp
hone
Antenna
Rear panel
Underside
Serial number
Control button
Tele/wid
e pull
er
DC-Iris
control cable
I/O terminal
connector
Power connector
Wireless indicator LED
Antenna
connector
Audio out
Audio in
Focus pul
ler
3
5
Table of Contents
