AXIS 211W Installation Guide Page 5
ENGLISH
ENGLISH
Install the hardware
Connect the cables and antenna
1. For indoor use, attach the antenna by screwing it into place. For outdoor use see the out-
door housing instructions.
2. Connect the camera to the network using a shielded network cable. This connection is
temporary and allows the camera’s settings to be configured via the wired network
before connecting to the wireless network.
3. Optionally connect external input/output devices, e.g. alarm devices. See page 16 for
information on the terminal connector pins.
4. Optionally connect an active speaker and/or external microphone.
5. Connect power, using one of the methods listed below:
• The supplied power connector.
• PoE (Power over Ethernet). If available, this is automatically detected when the
network cable is connected (see above).
• Connect power via the terminal connector. See page 16 for information on the
terminal connector pins.
6. Check that the indicator LEDs indicate the correct conditions. See the table on page 17
for further details. Note that some LEDs can be disabled and may be unlit.
!
IMPORTANT! - The AXIS 211W is designed for indoor and outdoor use. To use
the camera outdoors, it must be installed in an approved outdoor housing.
Please see www.axis.com for more information on outdoor housings.
