Technical Specifications - AXIS 216FD/216FD-V
Technical Specifications - AXIS 216FD/216FD-V
Item Specification
Models • AXIS 216FD: Tamper-resistant casing
• AXIS 216FD-V: Vandal-resistant casing
Image sensor ¼” Micron progressive scan RGB CMOS
Lens • Fujinon, F1.3 varifocal 2.8-10mm
• DC-iris
• Focus range: 0.3m to infinity
Angle of view AXIS 216FD: Horizontal: 73°-20°
Camera angle
adjustment
• Pan: 360°
• Tilt: 170°
• Rotation: 340°
Minimum
illumination
1 lux, F1.3
Video compression • Motion JPEG
• MPEG-4 Part 2 (ISO/IEC 14496-2) with motion estimation
• Profiles: Advanced Simple Profile and Simple Profile
Resolutions • 9 resolutions from 640x480 to 160x120 via API
• 6 selections via configuration web page
Frame rate • Up to 30 fps in all resolutions (Motion JPEG or MPEG-4)
Video streaming • Simultaneous Motion JPEG and MPEG-4
• Controllable frame rate and bandwidth
• Constant and variable bit rate (MPEG-4)
Image settings • Compression levels: 100
• Rotation: 0º, 180º
• Configurable color level, brightness, sharpness, contrast, white balance, exposure control
• Overlay capabilities: time, date, text, image or privacy mask
Shutter time 1/4 s to 1/15000 s
Audio • Configurable for built-in or external microphone
• Audio compression
- Audio in: AAC LC 8-32 kbit/s, G.711 PCM 64 kbit/s, G.726 ADPCM 32 or 24 kbit/s
- Audio out: G.711 PCM 64 kbit/s, G.726 ADPCM 32 or 24 kbit/s
• Half duplex, simplex or audio off
• Audio alarm at configurable detection level
Security • Multiple user access levels with password protection
• IP address filtering
• HTTPS encryption
• Network control IEEE 802.1X
Users • 20 simultaneous users
• Unlimited number of users using multicast (MPEG-4)
Alarm and event
management
• Events triggered by built-in multi-window motion detection, audio detection, external
input, or according to schedule
• Image upload over FTP, email and HTTP
• Notification over TCP, email, HTTP and external output
• Pre- and post alarm buffer of 9 MB (approx. 5 min of 320x240 resolution video at 4 fps)
