Technical Specifications - AXIS 216MFD/216MFD-V
Technical Specifications - AXIS 216MFD/216MFD-V
Item Specification
Models • AXIS 216MFD: Tamper-resistant casing
• AXIS 216MFD-V: Vandal-resistant casing
Image sensor 1/3” Micron progressive scan RGB 1.3 Megapixel CMOS
Lens • Fujinon, F1.3 varifocal 2.8-10mm
• DC-iris
• Focus range: 0.3m to infinity
Angle of view Horizontal: 27° - 100°
Camera angle
adjustment
• Pan: 360°
• Tilt: 170°
• Rotation: 340°
Minimum
illumination
2 lux, F1.3
Video compression • Motion JPEG
• MPEG-4 Part 2 (ISO/IEC 14496-2) with motion estimation
• Profiles: Advanced Simple Profile and Simple Profile
Resolutions • 24 resolutions from 1280x1024 to 160x90 via API
• 22 selections via configuration Web page
Frame rate • Motion JPEG: Up to 12 fps at 1280x1024
20 fps at 1024x768 (partial scan)
30 fps at 800x600 (partial scan)
• MPEG-4: Up to 8 fps at 1280x1024
13 fps at 1024x768 (partial scan)
20 fps at 800x600 (partial scan)
*Partial scan takes the data from the center region of the sensor and scales it down to
present an image at optimal frame rate.
Video streaming • Simultaneous Motion JPEG and MPEG-4
• Controllable frame rate and bandwidth
• Constant and variable bit rate (MPEG-4)
Image settings • Compression levels: 100
• Rotation: 0º, 180º
• Configurable color level, brightness, sharpness, contrast, white balance, exposure control,
fine tuning of behavior at low light
• Overlay capabilities: time, date, text, image or privacy mask
Shutter time 1/4 s to 1/15000 s
Audio • Configurable for built-in or external microphone
• Audio compression
- Audio in: AAC LC 8-32 kbit/s, G.711 PCM 64 kbit/s, G.726 ADPCM 32 or 24 kbit/s
- Audio out: G.711 PCM 64 kbit/s
• Half duplex, simplex or audio off
• Audio alarm at configurable detection level
