USER MANUAL
7
_____________________________________________________________________________________________________________________
7. Preparation
1. Take the scale out of the package
removing protective foils.
2. Take a pan off and remove protective
elements from below the pan.
3. Place the scale on a stable ground not
affected by mechanical vibrations and
airflows.
4. Level the scale with the rotating rear legs
so that the air bubble in the water-level at
the back of the scale is in the middle. Lock
the legs with the nut.
5. Put on the pan.
6. Remove everything from a pan and plug a
scale to the mains with a ground contact.
After self-tests and result stabilisation, the
scale displays zero indication.
7. In scales with external feeder connect feeder plug to a connector on a display post.
Plug a feeder to the mains (~230V, ground connector is not necessary).
To feed a scale use only socket with a ground connector.
Correct Wrong
