AXISM1034-WNetworkCamera
TechnicalSpecifications
Connectors
I/OConnector
4-pinterminalblock
Foranexamplediagram,seeConnectionDiagramsonpage63.
FunctionPinNotes
Specications
0VDC(-)
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
3.3VDC
Maxload=50mA
Digitalinput
3
Connecttopin1toactivate,orleaveoating(unconnected)
todeactivate
0tomax40VDC
Digitaloutput
4
Connectedtopin1whenactivated,oating(unconnected)
whendeactivated.Ifusedwithaninductiveload,e.g.arelay,
adiodemustbeconnectedinparallelwiththeload,for
protectionagainstvoltagetransients.
0tomax40VDC,opendrain,
100mA
ConnectionDiagrams
I/OConnector
1
0VDC(-)
2
DCoutput3.3V,max50mA
3
Digitalinput0tomax40VDC
4
Digitaloutput0tomax40VDC,opendrain,100mA
63
