Axis M1103 User Manual

AXISM1114
HardwareOverview
HardwareOverview
4
5
7
8
6
1
2
3
9
1.
NetworkLED
2.
StatusLED
3.
PowerLED
4.
Irisconnector
5.
Networkconnector
6.
Controlbutton
7.
Zoompuller
8.
Focuspuller
9.
ScrewholdingCSring
ConnectorsandButtons
Fortechnicalspecications,seepage52.
NetworkConnector
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
NO NO
NO
TICE TICE
TICE
Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnectingtheproducttothenetworkshall
beintendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledinaccordancewiththemanufacturer’s
instructions.Forinformationaboutregulatoryrequirements,seeElectromagneticCompatibility(EMC)onpage2.
ControlButton
Forlocationofthecontrolbutton,seeHardwareOverviewonpage6.
Thecontrolbuttonisusedfor:
•Resettingtheproducttofactorydefaultsettings.Seepage47.
•ConnectingtoanAXISVideoHostingSystemservice.Seepage41.Toconnect,pressandholdthebuttonforabout3
secondsuntiltheStatusLEDashesgreen.
•ConnectingtoAXISInternetDynamicDNSService.Seepage41.Toconnect,pressandholdthebuttonforabout3seconds.
6

Axis M1103 Specifications

General

Brand	Axis
Model	M1103
Category	Security Camera
Language	English
