Axis M1125 User Manual

AXISM11NetworkCameraSeries
2
Lockscrew
3
Focusring
4
Lens
Note
Afteradjustingzoomandfocus,ifoptimalcornerfocusisnot
achieved,rotatetheentirelenstothefactory-setpositionshown
intheillustrationabove.Thenslightlyrotatethelensclockwise
orcounter-clockwisetoreachfocusinallcorners.
ResettoFactoryDefaultSettings
Important
Resettofactorydefaultshouldbeusedwithcaution.Aresetto
factorydefaultwillresetallsettings,includingtheIPaddress,
tothefactorydefaultvalues.
Note
Theinstallationandmanagementsoftwaretoolsareavailable
fromthesupportpagesonwww.axis.com/techsup
Toresettheproducttothefactorydefaultsettings:
1.Disconnectpowerfromtheproduct.
2.Pressandholdthecontrolbuttonandreconnectpower.See
HardwareOverviewonpage10.
3.Keepthecontrolbuttonpressedfor15–30secondsuntilthe
statusLEDindicatorashesamber.
4.Releasethecontrolbutton.Theprocessiscompletewhenthe
statusLEDindicatorturnsgreen.Theproducthasbeenresetto
thefactorydefaultsettings.IfnoDHCPserverisavailableon
thenetwork,thedefaultIPaddressis192.168.0.90
5.Usingtheinstallationandmanagementsoftwaretools,assign
anIPaddress,setthepassword,andaccessthevideostream.
21
ENGLISH

Axis M1125 Specifications

General

Type	IP security camera
PTZ control	-
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Form factor	Box
Mounting type	Wall
Product color	White
Housing material	Polycarbonate (PC)
Total megapixels	1 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	160 x 90, 1920 x 1080 (HD 1080)
White balance	Auto
Camera shutter speed	1/143000 - 2 s
Minimum illumination	0.05 lx
Sensor type	CMOS
Optical sensor size	1/2.8 \
Optical zoom	- x
Focal length range	3 - 10.5 mm
Security algorithms	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Password protection type	User
Built-in HDD	No
Flash memory	256 MB
Internal memory	512 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RT CP, ICMP, DHCP, ARP, SOCKS, SSH
Compliance industry standards	PoE IEEE 802.3af
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Power source type	PoE
Power consumption (max)	5 W
Power consumption (typical)	3.6 W
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 85 %
Power source	PoE, DC

Weight and Dimensions

Depth	70 mm
Width	44 mm
Height	148 mm
Weight	200 g
