Axis M1145 Installation Guide

AXISM1145Series
NO NO
NO
TICE TICE
TICE
Duetolocalregulationsortheenvironmentalandelectrical
conditionsinwhichtheproductistobeused,ashieldednetwork
cable(STP)maybeappropriateorrequired.Allcablesconnecting
theproducttothenetworkandthatareroutedoutdoorsorin
demandingelectricalenvironmentsshallbeintendedfortheir
specicuse.Makesurethatthenetworkdevicesareinstalledin
accordancewiththemanufacturer’sinstructions.Forinformation
aboutregulatoryrequirements,seeElectromagneticCompatibility
(EMC)2.
I/OConnector
Usewithexternaldevicesincombinationwith,forexample,tampering
alarms,motiondetection,eventtriggering,timelapserecordingandalarm
notications.Inadditiontothe0VDCreferencepointandpower(DC
output),theI/Oconnectorprovidestheinterfaceto:
•Digitaloutput–Forconnectingexternaldevicessuchasrelays
andLEDs.ConnecteddevicescanbeactivatedbytheVAPIX®
ApplicationProgrammingInterface,outputbuttonsonthe
LiveViewpageorbyanActionRule.Theoutputwillshowas
active(shownunderSystemOptions>Ports&Devices)if
thealarmdeviceisactivated.
•Digitalinput–Analarminputforconnectingdevicesthat
cantogglebetweenanopenandclosedcircuit,forexample:
PIRs,door/windowcontacts,glassbreakdetectors,etc.When
asignalisreceivedthestatechangesandtheinputbecomes
active(shownunderSystemOptions>Ports&Devices).
SDCardSlot
NO NO
NO
TICE TICE
TICE
•RiskofdamagetoSDcard.Donotusesharptoolsorexcessive
forcewheninsertingorremovingtheSDcard.
•Riskofdataloss.Topreventdatacorruption,theSDcardshould
beunmountedbeforeremoval.Tounmount,gotoSetup>
SystemOptions>Storage>SDCardandclickUnmount.
13

Axis M1145 Specifications

General

Type	-
PTZ control	Yes
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Cube
Mounting type	Wall
Product color	White
Housing material	Aluminum
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, MPEG4
Supported graphics resolutions	1920 x 1080 (HD 1080)
White balance	Auto
Angle of rotation	270 °
Camera shutter type	Electronic
Camera shutter speed	1/33500 s
Minimum illumination	0.08 lx
Field of view (FOV) angle	112 °
Sensor type	CMOS
Optical sensor size	1/2.9 \
Optical zoom	- x
Focal length range	3 - 10.5 mm
Security algorithms	HTTPS
Password protection type	User
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
LED type	IR
Cabling technology	10/100Base-T(X)
Supported network protocols	HTTP, HTTPS, SSL/TLS*, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, CIFS/SMB, SSH
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
DC output voltage	+3.3V
Power consumption	50 mA
Power source type	PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	6 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Minimum RAM	256 MB

Weight and Dimensions

Depth	46 mm
Width	75 mm
Height	115 mm
Weight	250 g
