Axis M1145 User Manual

AXISM1145NetworkCamera
Howtosetuptheproduct
Aboutprivacymasks
Aprivacymaskisauser-denedareathatcoverspartsofthemonitoredarea.Privacymasksappearasblocksofsolidcolorandare
appliedonthevideostream.PrivacymaskscannotbebypassedusingtheVAPIX®applicationprogramminginterface(API).
ThePrivacyMaskList(Video>PrivacyMask)showsallthemasksthatarecurrentlyconguredintheAxisproductandindicates
iftheyareenabled.
Youcanaddanewmask,re-sizethemaskwiththemouse,chooseacolorforthemask,andgivethemaskaname.
Formoreinformation,seetheonlinehelp
Important
Addingmanyprivacymasksmayaffecttheproduct’sperformance.
Setfocusandzoom
1.InstallthecameraasdescribedintheInstallationGuide.
2.GotoSetup>Video.
3.OnthefocuspagegototheBasictab.
4.Setthezoomlevelusingtheslider.
Note
Movementsinfrontofthecamerashouldbeavoidedwhenperformingautofocus.
5.ClickPerformautofocus.
6.Iftheresultisnotsatisfactory,gototheAdvancedtab.
OntheAdvancedtab,focuscanbeadjustedmanually:
1.ClickOpeniristoopentheiristoitsmaximumposition.Thisgivesthesmallestdepthofeldandprovidesthebest
conditionsforfocusing.
2.FocusissetintheFocuswindow.Usethemousetomoveandresizethefocuswindow.
3.ClickintheFocuspositionbartofocusonadesiredlocation.
4.Whensatised,clickEnableiristoenabletheiris.
23

Axis M1145 Specifications

General

Type	-
PTZ control	Yes
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Cube
Mounting type	Wall
Product color	White
Housing material	Aluminum
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, MPEG4
Supported graphics resolutions	1920 x 1080 (HD 1080)
White balance	Auto
Angle of rotation	270 °
Camera shutter type	Electronic
Camera shutter speed	1/33500 s
Minimum illumination	0.08 lx
Field of view (FOV) angle	112 °
Sensor type	CMOS
Optical sensor size	1/2.9 \
Optical zoom	- x
Focal length range	3 - 10.5 mm
Security algorithms	HTTPS
Password protection type	User
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
LED type	IR
Cabling technology	10/100Base-T(X)
Supported network protocols	HTTP, HTTPS, SSL/TLS*, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, CIFS/SMB, SSH
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
DC output voltage	+3.3V
Power consumption	50 mA
Power source type	PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	6 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Minimum RAM	256 MB

Weight and Dimensions

Depth	46 mm
Width	75 mm
Height	115 mm
Weight	250 g
