Axis M2025-LE User Manual

AXISM2025-LENetworkCamera
Setup
Findoutmoreataxis.com/axis-corridor-format
Streamingandstorage
Choosevideocompressionformat
Decidewhichcompressionmethodtousebasedonyourviewingrequirements,andonthepropertiesofyournetwork.The
availableoptionsare:
MotionJPEG
MotionJPEGorMJPEGisadigitalvideosequencethatismadeupofaseriesofindividualJPEGimages.Theseimagesarethen
displayedandupdatedataratesufcienttocreateastreamthatshowsconstantlyupdatedmotion.Fortheviewertoperceivemotion
videotheratemustbeatleast16imageframespersecond.Fullmotionvideoisperceivedat30(NTSC)or25(PAL)framespersecond.
TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage
containedinthestream.
H.264orMPEG-4Part10/AVC
Note
H.264isalicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed
copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.
H.264can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebymorethan80%comparedtotheMotion
JPEGformatandbyasmuchas50%comparedtotheMPEG-4standard.Thismeansthatlessnetworkbandwidthandstoragespace
arerequiredforavideole.Orseenanotherway,highervideoqualitycanbeachievedforagivenbitrate.
Reducebandwidthandstorage
Important
Ifyoureducethebandwidthitcanresultinlossofdetailsinthepicture.
1.GotoliveviewandselectH.264.
2.GotoSettings>Stream.
3.Dooneormoreofthefollowing:
-TurnontheZipstreamfunctionalityandselectthedesiredlevel.
-TurnondynamicGOPandsetahighGOPlengthvalue.
-Increasethecompression.
-TurnondynamicFPS.
Setupnetworkstorage
Tostorerecordingsonthenetwork,youneedtosetupnetworkstorage:
1.GotoSettings>System>Storage.
2.ClickSetupunderNetworkstorage.
3.EntertheIPaddressofthehostserver.
4.Enterthenameofthesharedlocationonthehostserver.
5.Movetheswitchifthesharerequiresalogin,andenterusernameandpassword.
11

Axis M2025-LE Specifications

General

Form factor	Bullet
Mounting type	Ceiling/wall
Product color	Black
Housing material	Polymer
International Protection (IP) code	IP66
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/2.8 \
Lens mount interface	M12
Fixed focal length	2.8 mm
Maximum aperture number	2
Angle of rotation	270 °
Camera shutter speed	1/65000 - 2 s
Minimum illumination	0.04 lx
Type	IP security camera
Languages support	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POR, RUS
Number of languages	11
Placement supported	Outdoor
Connectivity technology	Wired
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, M-JPEG, MPEG4
Image quality adjustment	Brightness, Contrast, Sharpness
Supported graphics resolutions	1920 x 1080 (HD 1080)
Security algorithms	HTTPS, SNMP, SSH, SSL/TLS
Alert notification type	E-mail
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3af, IEEE 802.3at
Minimum RAM	512 MB
Power source type	PoE
Power consumption (max)	6.3 W
Power consumption (Power over Ethernet (PoE))	4.1 W
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	15 m
Built-in HDD	-
Compatible memory cards	SD, SDHC, SDXC
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	10 - 100 %
Interface	RJ-45
Number of cameras	1
Harmonized System (HS) code	85258900

Weight and Dimensions

Weight	500 g
Diameter	101 mm
