AXISM30NetworkCameraSeries
Thedeviceinterface
Audiodetection
Thesesettingsareavailableforeachaudioinput.
Soundlevel:Adjustthesoundleveltoavaluefrom0–100,where0isthemostsensitiveand100theleastsensitive.Usethe
activityindicatorasaguidewhenyousetthesoundlevel.Whenyoucreateevents,youcanusethesoundlevelasacondition.
Youcanchoosetotriggeranactionifthesoundlevelrisesabove,fallsbeloworpassesthesetvalue.
Videoout
HDMI
YoucanconnectanexternalmonitortothedevicethroughanHDMIcable.
Singlesource
Astreamfromasinglecameraisdisplayedontheexternalmonitor.
•Source:Selectonlyonecamera.
•Rotateimage180°:Clicktorotatetheimage.
•Mirrorimage:Clicktoiptheimage.
•Dynamicoverlays:Clicktooverlay.
Quadview
Viewstreamsfromfourseparatecamerasatthesametimeontheexternalmonitor.
•Sources:Selectadifferentcamerafromeachofthefourdrop-downlists.Theimagebesidethesourceshowswhere
thevideofromthatcamerawillbedisplayedonthescreen.
•Rotateimage180°:Clicktorotateallimages.
Playlist
Singlestreamsfrommultiplecamerasalternateontheexternalmonitor.
•Rotateimage180°:Clicktorotatetheimagefromallsources.
•
:Clicktoaddacameratotheplaylist.
•Source:Selectthedesiredcamera.
•Duration:Sethowlong(inmm:ss)theplaylistwillstreamfromthiscameraineachrotation.
•Mirrorimage:Clicktoiptheimage.
•Create:Clicktosave.
Picture-in-picture
Twostreamsaredisplayedontheexternalmonitoratthesametime.Onestreamllsthedisplayandtheotherisasmaller
picture.Position,picturesizeandbordersarecustomizable.
•Picture-in-picture
-Source:Selectthecamerathatwillstreamasthesmallerpicture.
-Rotateimage180°:Clicktorotatetheimage.
-Mirrorimage:Clicktoiptheimage.
-Position:Selectwhereonthescreenthepictureshouldappear.
-Picturesize:Dragtheslidertosetthesize(%ofscreen)ofthepicture.
-Border:Clicktotogglebordersforthepictureonoroff.
-
:Dragtheslidertosetthethicknessfortheentireborder.
-
:Dragtheslidertosetthethicknessforthetopborder.
-
:Dragtheslidertosetthethicknessfortherightborder.
-
:Dragtheslidertosetthethicknessforthebottomborder.
-
:Dragtheslidertosetthethicknessfortheleftborder.
-Bordercolor:Selectabordercolor.
•Mainview
41

Axis M30 Series Specifications

General

Day/Night functionality	Yes
Ingress Protection	IP42, IP66, IP67 Depending on the specific model
Lens	Fixed lens
Wide Dynamic Range	Yes
Power over Ethernet	Yes
Indoor/Outdoor	Indoor
Video Compression	H.264, H.265, MJPEG
Impact Protection	IK10
Sensor Type	CMOS
Day/Night	Automatically removable infrared-cut filter
Ethernet	10/100 Mbps
Power over Ethernet (PoE)	IEEE 802.3af
Power Supply	Power over Ethernet (PoE)
Vandal Resistance	IK10
Dimensions	Varies depending on the specific model
Weight	Varies depending on the specific model
