AXISP12NetworkCameraSeries
5.CheckthattheindicatorLEDsindicatethecorrectconditions.Seeforfurtherdetails.
NotethatsomeLEDscanbedisabledandmaybeunlit.
ShortenSensorUnitCable
Thesensorunitisdeliveredwithacable.Notethatthiscablecannotbeextended.Toshorten
thecablefollowthesesteps:
1.Cutthecabletothedesiredlength.Measurefromthesensorunit.
2.Striptheplasticoutercoatingfromtheendofthecable.
3.Peelbacktheshield.
4.Flattenthecoloredwiresintheorderdescribedbelow.
1
Brown
2
White/brown
3
Notused
4
Notused
5
White/blue
6
Blue
NO NO
NO
TICE TICE
TICE
Makesurethatthewiresstayinthecorrectorderandthatthecableshieldmakesgood
contactwiththeconnectorshield.
5.Insertthewiresallthewayintoashielded6P6CRJ12connector.
6.Useacrimpingtooltofastentheconnectortothecable.
