AXIS P1343/-E/AXIS P1344/-E - Technical Specifications for AXIS P1343/AXIS P1343-E
Technical Specifications for AXIS P1343/AXIS P1343-E
Function/group Item Specification
Camera Models SVGA resolution, day and night
Image sensor Progressive scan RGB CMOS ¼”
Lens • Varifocal 3 - 8 mm, F1.4, DC-iris, CS mount
• Horizontal angle of view: 59° - 25°
• Vertical angle of view: 42° - 18°
• Diagonal angle of view: 74° - 31°
• Remote back focus
• Focus range: 0.2 m to infinity
Day and night
functionality
Automatically removable infrared-cut filter
Minimum
illumination
• Color: 0.3 lux, F1.4
• B/W: 0.05 lux, F1.4
Shutter time 1/24500 s to 1/6 s
Video Video compression • H.264 Baseline profile (MPEG-4 Part 10/AVC)
• Motion JPEG
Resolutions 800x600 (SVGA) to 160x90
Frame rate H.264 30 fps in all resolutions
Frame rate
Motion JPEG
30 fps in all resolutions
Video streaming • Multi-stream H.264 and Motion JPEG
• H.264 and Motion JPEG: 2 individually configured streams in full resolution
and frame rate. More streams if identical or limited in frame rate or
resolution.
• Controllable frame rate and bandwidth
• VBR/CBR H.264
Pan/Tilt/Zoom Digital PTZ, preset positions, guard tour
Image settings • Compression, color, brightness, sharpness, contrast, white balance, exposure
control, exposure zones, backlight compensation, wide dynamic range with
dynamic contrast, fine tuning of behavior at low light
• Rotation: 0°, 90°, 180°, 270°
• Mirroring of images
• Text and image overlay
• Privacy mask
Users • 20 simultaneous users
• Unlimited number of users using multicast (H.264)
Audio Audio streaming Two-way, full duplex
Audio compression • AAC LC 8 kHz 32 kbit/s, 16 kHz 64 kbit/s
• G.711 PCM 8 kHz 64 kbit/s
• G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s
Audio input/output • External microphone input or line input
• Line output
• AXIS P1343: Built-in microphone
Network Security Password protection, IP address filtering, HTTPS encryption*, IEEE 802.1X
network access control*, digest authentication, user access log
*This product includes software developed by the Open SSL Project for use in
the Open SSL Tool kit (www.openssl.org)
Supported protocols IPv4/v6, HTTP, HTTPS*, SSL/TLS*, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour,
UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP,
IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, etc.
*This product includes software developed by the Open SSL Project for use in
the Open SSL Tool kit (www.openssl.org)
