AXISP1365-ENetworkCamera
AudioConnector
3.5mmaudio
connectors(stereo)
123
1Tip2Ring
3Sleeve
AudioInput
Microphone/Linein
Ground
AudioOutput
Lineout(mono)
Ground
RS485/422Connector
Two2-pinterminalblocksforRS485/RS422serial
interface.Theserialportcanbeconguredtosupport:
•Two-wireRS485halfduplex
•Four-wireRS485fullduplex
•Two-wireRS422simplex
•Four-wireRS422fullduplexpointtopoint
communication
RS485/422
1 2
RX/TX TX
3 4
FunctionPinNotes
RS485Balt
RS485/422RX(B)
1
RS485Aalt
RS485/422RX(A)
2
RXpairforallmodes(combinedRX/TXfor2-wireRS485)
RS485/RS422TX(B)
3
RS485/RS422TX(A)
4
TXpairforRS422and4-wireRS485
Important
Therecommendedmaximumcablelengthis30m(98.4ft).
SDCardSlot
TheAxisproductsupportsmicroSDcardswithupto64GBofstorage.Forbestrecording
performance,useultra-highspeedmicroSDcards(microSDHCUHS-IormicroSDXCUHS-I).
