Page #30 background imageLoading...
Page #30 background image
AXIS P3343 Fixed Dome Network Camera
Detectors
Recommended values
5–15% 60–90% 75–95%
Default values
15% 90% 90%
Tips:
To trigger on small objects or movements, use several small m otion detection windows rather than one large window
and select a low object size.
To a void triggering on small objects, select a high object size.
If no objects should appear in the Include Window, select a high history level. This will cause motion detection to trigger as
long as the object is present in the window.
To only detect ashing light, select a low sensitivity. In other cases high sensitivity is recommended.
Audio detection
The Axis product can be congured to generate an alarm when audio rises above or falls below the threshold value. The threshold
value can be set in the range 0–100 where 0 is the most sensitive and 100 the l east sensitive.
1. Go to Detectors > Audio Detection.
2. Set the audio alarm level and click Save.
3. Go to Events > Action Rules and set up an action rule, see Setting Up an Action Rule, on page 32.
Detected audio is indicated by colored peaks in the Activity indi cator. An event is triggered when detected audio rises above or falls
below the threshold v alue, which is represented by the bar.
30

Other manuals for Axis P3343

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Axis P3343 and is the answer not in the manual?

Axis P3343 Specifications

General IconGeneral
Maximum frame rate30 fps
Maximum video resolution800 x 600 pixels
Built-in microphoneYes
I/O ports1 x Ethernet
Compatible memory cardsSD, SDHC
Compliance industry standardsIEEE 802.3af
