AXISP5676-LEPTZCamera
Configureyourdevice
Thisexampleexplainshowtodirectthecameraandopenagatewhensomeonewantstoenterduringdaytime.Thisisdoneby
connectingaPIRdetectortotheproduct’sinputportandaswitchrelaytotheproduct’soutputport.
Requiredhardware
•Multicable(soldseparately),seeMulticonnectoronpage64.
•MountedPIRdetector
•Switchrelayconnectedtothegatelock,inthiscasetheswitchisnormallyclosed(NC)
•Connectingwires
Physicalconnection
1.Removetheplugfromthecamera’smulti-connectorandconnectthemulticable.
2.ConnectthewiresfromthePIRdetectortotheinputpin,seeMulticonnectoronpage64.
3.Connectthewiresfromtheswitchtotheoutputpin,seeMulticonnectoronpage64.
1.ConnectthewiresfromthePIRdetectortotheinputpin,see.
2.Connectthewiresfromtheswitchtotheoutputpin,see
CongureI/Oports
Youneedtoconnecttheswitchrelaytothecamerafromthecamera’swebinterface.First,conguretheI/Oports:
SetthePIRdetectortoaninputport
1.GotoSystem>Accessories>I/Oports.
2.Click
tosetthedirectiontoinputforport1.
3.Givetheinputmoduleadescriptivename,forexample“PIRdetector”.
4.IfyouwanttotriggeraneventwheneverthePIRdetectorsensesmotion,click
tosetthenormalstatetocircuitopen.
Settheswitchrelaytoanoutputport
1.Click
tosetthedirectiontooutputforport2.
2.Givetheoutputmoduleadescriptivename,forexample“Gateswitch”.
3.Ifyouwanttoopenthegatewheneveraneventistriggered,clicktosetthenormalstatetocircuitclosed.
Createrules
ForthecameratoopenthegatewhenthePIRdetectorsensessomeonenearby,youneedtocreatearuleinthecamera:
1.GotoSystem>Eventsandaddarule.
2.Typeanamefortherule,forexample“Opengate”.
3.Inthelistofconditions,selectPIRdetector.
4.Inthelistofactions,selectToggleI/Oonce.
5.Inthelistofports,selectGateswitch.
18
