AXISP5676-LEPTZCamera
Specifications
Multicableconnectors
Multicableoverview
1
Cameramulticonnector
2
I/Oterminalblock
3
Audioterminalblock
4
Powerconnector
Themulticableprovidesthefollowingconnectors:
Powerconnector-2-pinterminalblockusedforpowerinput.Thepolarityofthecablesdoesnotmatter.UseaSafetyExtra
LowVoltage(SELV)compliantlimitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100Woraratedoutput
currentlimitedto≤5A.
Audioconnector-4–pinterminalblockusedforaudioinandaudiolineout.Thiscanbeconnectedtoapublicaddress(PA)system
oranactivespeakerwithabuilt-inamplier.
FunctionPinNotes
AudioIn
1
Balancedorunbalancedinputforamonomicrophoneorlinesignal
AudioLineOut
3
Canbeconnectedtoapublicaddress(PA)systemoranactivespeakerwithabuilt-in
amplier
GND
2,4
Ground
I/Oterminalconnector-Usewithexternaldevicesincombinationwith,forexample,tamperingalarms,motiondetection,event
triggering,andalarmnotications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/Oconnectorprovidesthe
interfaceto:
•Digitaloutput—ForconnectingexternaldevicessuchasrelaysandLEDs.Connecteddevicescanbeactivatedby
theVAPIX®ApplicationProgrammingInterfaceorfromthedevice’swebinterface.
•Digitalinput—Forconnectingexternaldevicesthatcantogglebetweenanopenandclosedcircuit,forexample
PIRdetectors,door/windowcontacts,andglassbreakdetectors.
