AXISP5676-LEPTZCamera
Specifications
FunctionPinNotes
Specications
0VDC(-)
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
Maxload=50mA
Digitalinput–Connecttopin1toactivate,orleave
oating(unconnected)todeactivate.
0tomax30VDC
Congurable(Input
orOutput)
3–6
Digitaloutput–Internallyconnectedtopin1(DC
ground)whenactive,andoating(unconnected)when
inactive.Ifusedwithaninductiveload,e.g.arelay,a
diodemustbeconnectedinparallelwiththeload,for
protectionagainstvoltagetransients.
0tomax30VDC,open
drain,100mA
1
0VDC(-)
2
DCoutput12V,max50mA
A
I/Oconguredasinput
B
I/Oconguredasoutput
Axis10-pinpush-pullsystemconnector(soldseparately)
WhenconnectingexternalequipmenttotheAxisproduct,anAxis10-pinPush-PullSystemConnector(soldseparately)isrequiredin
ordertomaintaintheproduct’sIPrating.
Mountingthewiresrequiresacrimptool.Togetdetailedmountinginstructionsofthewires,gotoaxis.com/support.
Connectthe10-pinpush-pullsystemconnectortotheproduct’smulti-connector.Tolocatethemulti-connectorgoto.
