Page 12 AXIS P8221 Installation Guide
Set the IP address with ARP/Ping
1. Acquire a free static IP address on the same network segment your computer is connected to.
2. Locate the serial number (S/N) on the device’s label.
3. Open a command prompt on your computer and enter the following commands:
4. Check that the network cable is connected and then start/restart AXIS P8221, by disconnecting
and reconnecting power. If PoE is used, start/restart the device by disconnecting and then
reconnecting the network cable.
5. Close the command prompt when you see ‘Reply from 192.168.0.125:...’ or similar.
6. In your browser, type in http://<IP address> in the Location/Address field and press Enter on
your keyboard.
Notes:
• To open a command prompt in Windows: from the Start menu, select Run... and type cmd. Click OK.
• To use the ARP command in Windows Vista, right-click the command prompt icon and select Run as
administrator.
• To use the ARP command on a Mac OS X, use the Terminal utility in Application > Utilities.
Windows syntax
arp -s <IP Address> <Serial Number>
ping -l 408 -t <IP Address>
Windows example
arp -s 192.168.0.125 00-40-8c-18-10-00
ping -l 408 -t 192.168.0.125
UNIX/Linux/Mac syntax
arp -s <IP Address> <Serial Number> temp
ping -s 408 <IP Address>
UNIX/Linux/Mac example
arp -s 192.168.0.125 00:40:8c:18:10:00 temp
ping -s 408 192.168.0.125

Axis P8221 Specifications

General

Relay Outputs	2
Digital Inputs	4
Enclosure	Plastic
Audio Output	Terminal block for one balanced audio output
Power over Ethernet	Yes
Connectors	Terminal block
Power	PoE (IEEE 802.3af)
Protocols	HTTP, HTTPS, SSL/TLS, IPv4, IPv6, Bonjour, UPnP, QoS, SNMP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, DNS
Network Interface	10/100 Mbit/s Ethernet
Output channels	2
Input type	Digital, audio
Maximum load voltage per output	30 V DC
Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Dimensions (alternative)	4.3 x 2.9 x 1.4 in
Weight (alternative)	0.3 lb
