AXISQ16NetworkCameraSeries
Configureyourdevice
Configureyourdevice
Basicsettings
Setthecapturemode
1.GotoVideo>Installation>Capturemode.
2.ClickChange.
3.SelectacapturemodeandclickSaveandrestart.
SeealsoCapturemodesonpage51.
Setthepowerlinefrequency
1.GotoVideo>Installation>Powerlinefrequency.
2.ClickChange.
3.SelectapowerlinefrequencyandclickSaveandrestart.
Settheorientation
1.GotoVideo>Installation>Rotate.
2.Select0,90,180or270degrees.
SeealsoMonitorlongandnarrowareasonpage10.
Replacethelens
1.Stopallrecordingsanddisconnectpowerfromthedevice.
2.Disconnectthelenscableandremovethestandardlens.
3.Attachthenewlensandconnectthelenscable.
4.Reconnectthepower.
5.Logintothedevice’swebinterfaceandgotoVideo>Image>Exposure.
6.SelecttheP-Irislensyouhaveinstalled.
Note
IfyouuseaDCiris,manualirisoroptionali-CSlensthereisnoneedtoselectalensdriver.
7.Forthechangestotakeeffect,youneedtorestartthedevice.GotoMaintenanceandclickRestart.
8.Adjustthezoomandfocus.
Note
ForalenswithP-Iris,DC-iris,ormanualiris,manuallyadjustthefocusonthelensbeforeyoune-tunethefocusthrough
thewebinterface.
Adjusttheimage
Thissectionincludesinstructionsaboutconguringyourdevice.Ifyouwanttolearnmoreabouthowcertainfeatureswork,go
toLearnmoreonpage50.
6
