AXIS Q1602/Q1604 Network Camera Installation Guide Page 7
ENGLISH
Dimensions
Install the hardware
Connect the cables
1. Optionally connect external input/output devices, such as alarm devices. See page 18 for infor-
mation on the terminal connector pins.
2. Optionally connect an active speaker and/or external microphone.
3. Connect the camera to the network using a shielded network cable.
4. Connect power, using one of the methods listed below:
• PoE (Power over Ethernet). PoE is automatically detected when the network cable is
connected.
• Connect an external power adapter to the power connector block; see
Unit connectors,
on page 17 for wiring information.
5. Check that the indicator LEDs indicate the correct conditions. See the table on page 19 for
more details. Note that the Status LED can be configured to be unlit during normal operation.
Cold Start-up Delay Switch
Enable this switch for AXIS Q1602/Q1604.
The housing used in this Axis product features Arctic Temperature Control, which is enabled by
setting the Cold Start-up Delay switch to I (ON). When enabled, this function controls when the
camera restarts after a power cut, when temperatures are below 0 °C (32 °F); the camera is first
heated to approximately 0 °C (32 °F) before it initializes. This prevents damage to camera parts that
are sensitive to sub-zero temperatures.
Model H x W x D Weight
AXIS Q1602 46 x 78 x 192 mm (1.8” x 3.1” x 7.6”) 630 g (1.39 lb)
AXIS Q1604 46 x 78 x 192 mm (1.8” x 3.1” x 7.6”) 630 g (1.39 lb)
!
IMPORTANT! - AXIS Q1602/Q1604 is designed for indoor and outdoor use. To use the
camera outdoors, it must be installed in an approved outdoor housing. Please see
www.axis.com for more information on outdoor housings.
