Axis Q1604 User Manual

AXISQ1604-ENetworkCamera
HardwareOverview
SDCardSlot
AnSDcard(notincluded)canbeusedforlocalrecordingwithremovablestorage.Formoreinformation,seeTechnicalSpecications.
NOTICE NOTICE
NOTICE
Topreventcorruptionofrecordings,theSDcardshouldbeunmountedbeforeremoval.Tounmount,gotoSetup>System
Options>Storage>SDCardandclickUnmount.
ControlButton
Thecontrolbuttonisusedfor:
•EnablingtheFocusAssistant.PressandveryquicklyreleasetheControlbutton.
•Resettingtheproducttofactorydefaultsettings.Seepage54.
•ConnectingtoanAXISVideoHostingSystemservice.Seepage47.Toconnect,pressandholdthebuttonforabout1
seconduntiltheStatusLEDashesgreen.
•ConnectingtoAXISInternetDynamicDNSService.Seepage47.Toconnect,pressandholdthebuttonforabout3seconds.
LEDIndicators
LEDindicatorsincamera
LED
Color
Indication
Green
Steadyforconnectiontoa100Mbit/snetwork.Flashesfornetworkactivity.
Amber
Steadyforconnectionto10Mbit/snetwork.Flashesfornetworkactivity.
Network
UnlitNonetworkconnection.
GreenSteadygreenfornormaloperation.
Amber
Steadyduringstartup,duringresettofactorydefaultorwhenrestoringsettings.
Status
Red
Slowashforfailedupgrade.
Power
Green
Normaloperation.
Amber
Flashesgreen/amberduringrmwareupgrade.
Note
•TheStatusLEDcanbeconguredtoashwhileaneventisactive.
•TheStatusLEDcanbeconguredtobeunlitduringnormaloperation,ortoashonlywhenthecameraisaccessed.To
congure,gotoSetup>SystemOptions>LEDsettings.Seetheonlinehelplesformoreinformation.
•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.ThiscanbedoneunderSetup>SystemOptions>
Maintenance.
StatusLEDonhousing(fanandheater)
Color
Indication
GreenOK
Flashing
green
Singleash:Heatererror
Doubleash:Fanerror
Tripleash:Generalerror
Alarmeventswillbetriggeredthroughthecamera’sinputport.
SeetheUser’sManual,availableontheCDprovidedwiththisproduct,orfromwww.axis.com
ContactyourAxisresellerforinformationaboutsparepartsandtroubleshooting.
10
