AccessingtheProduct
2.Enterapasswordandthenre-enterittoconrmthespelling.
3.ClickOK.Thepasswordhasnowbeencongured.
CongureCaptureMode
Thecapturemodesettingreducesimageickerinuorescentlightenvironments.Selectthecapturemodewiththepowerline
frequency(50Hzor60Hz)usedatthelocationoftheAxisproductandclickOK.
Whenusing50Hz,themaximumframerateislimitedto25fps.
Note
Powerlinefrequencyisdifferentindifferentgeographicregions.IntheAmericas,60Hzisusuallyused;mostotherpartsof
theworlduse50Hz.Localvariationsmayapply,alwayscheckwiththelocalauthorities.
SeealsoCaptureMode,onpage23.
TheLiveViewPage
ThecontrolsandlayoutoftheLiveViewpagemayhavebeencustomizedtomeetspecicinstallationrequirementsanduser
preferences.Consequently,someoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedinyourownLiveView
page.Thefollowingprovidesanoverviewofeachavailablecontrol.
ControlsontheLiveViewPage
SelectastreamprolefortheLiveViewpagefromtheStreamProledrop-downlist.Forinformationabouthow
tocongurestreamproles,seepage23.
ClickPulsetoactivatetheproduct’soutputportforadenedperiodoftime.Forinformationabouthowtoenable
andcongureoutputbuttons,seepage30.
ClicktheActive/Inactivebuttonstomanuallyactivateandinactivetheproduct’soutputport.Forinformation
abouthowtoenableandcongureoutputbuttons,seepage30.
TheManualTriggerbuttonisusedtotriggeranactionrulefromtheLiveViewpage.Forinformationabouthowto
congureandenablethebutton,seeManualTrigger,onpage14.
ClickSnapshottoopenanewwindowwithasnapshotimageofthevideostream.Right-clickontheimageto
saveitasPNG.ThisbuttonisprimarilyintendedforusewithbrowsersotherthanMicrosoftInternetExplorer,or
whenotherwisenotusingActiveXtoviewthevideostream.EnablethisbuttonfromLiveViewCong>Action
Buttons.TheActiveXviewingcomponentforMicrosoftInternetExplorer(AXISMediaControl)providesitsown
snapshotbutton,whichisenabledbydefault.
TheAudioclipdrop-downlistallowsyoutoplayanaudioclipfromtheLiveViewpage.Selecttheaudio
clipandclickthePlaybutton.
ManualTrigger
TheManualTriggerisusedtotriggeranactionrulefromtheLiveViewpage.Themanualtriggercanforexamplebeusedto
validateactionsduringproductinstallationandconguration.
Tocongurethemanualtrigger:
