AXISQ1604-ENetworkCamera

SettingUptheProduct

TheAxisproductcanbeconguredbyuserswithadministratororoperatorrights.Toopentheproduct’sSetuppages,clickSetupin

thetopright-handcorneroftheLiveViewpage.

•Administratorshaveunrestrictedaccesstoallsettings.

•OperatorshaveaccesstoallsettingsexceptSystemOptions

Seealsotheonlinehelp

BasicSetup

BasicSetupprovidesshortcutstothesettingsthatshouldbemadebeforeusingtheAxisproduct:

1.Users.Seepage43.

2.TCP/IP.Seepage46.

3.Date&Time.Seepage45.

4.VideoStream.Seepage21.

5.Focus.See

6.AudioSettings.Seepage27.

TheBasicSetupmenucanbedisabledfromSystemOptions>Security>Users.

AdjustFocus

Toadjustthezoomandfocusfollowtheseinstructions:

Note

•SetfocusaspreciselyaspossiblewiththefocuspullerorFocusAssistantbeforestartingautomaticnetuning.Usingthe

focuspullernormallygivesthebestresult.

•Theirisshouldalwaysbeopenedtoitsmaximumwhilefocusing.Thisgivesthesmallestdepthofeldandthusthe

bestconditionsforcorrectfocusing.

1.Opentheproduct’shomepageandgotoSetup>BasicSetup>Focus.

2.UndertheBasictab,clickOpeniris.Ifthebuttonisinactivetheirisisalreadyopen.

3.Iffocushasbeensetbefore,clickResettoresetthebackfocus.

4.Loosenthezoomandfocuspullers(seeHardwareOverview,onpage6)onthelensbyturningthemcounter-clockwise.

Movethepullerstosetzoomandfocusandcheckthequalityoftheimageintheimagewindow.Ifthecamerais

mountedsothatonecannotlookattheimageandmovethepullersatthesametime,usetheFocusAssistantinstead.

SeeFocusAssistant,onpage20.

5.Re-tightenthezoomandfocuspullers.

6.OntheFocuspage,clickFine-tunefocusautomaticallyandwaituntilautomaticnetuningiscompleted.

7.ClickEnableiris.Ifthebuttonisinactivetheirisisalreadyenabled.

8.Ifneeded,makefurtheradjustmentsundertheAdvancedtab.Seetheonlinehelpformoreinformation.
