Axis Q1798-LE - Connectors

AXISQ1798-LENetworkCamera
Specifications
Connectors
Networkconnector
RJ45EthernetconnectorwithPoweroverEthernetPlus(PoE+).
IDCconnector
Usetheinsulation-displacementconnector(IDC)toconnectanetworkcablewithoutanRJ45-connector.
Note
WhenusingtheIDCconnector,connectapatchcablebetweenthepatchcableconnectoronthefootandthenetwork
connectoronthecameraassembly.
1–8
IDCconnectors
9
Patchcableconnector
Pinassignment
PositionT586AT586B
1
BlueandwhiteBlueandwhite
2
BlueBlue
3
OrangeandwhiteGreenandwhite
4
OrangeGreen
5
GreenandwhiteOrangeandwhite
6
GreenOrange
7
BrownandwhiteBrownandwhite
8
BrownBrown
Audioconnector
•Audioin–3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisusedfromastereosignal).
Audioinput
1Tip2Ring
3Sleeve
Unbalancedmicrophone(withorwithoutelectret
power)orline
Electretpowerifselected
Ground
35
