AXISQ6045-SMkIIPTZDomeNetworkCamera
Technicalspecifications
DCoutput
2
Powerout
12VDC,50mA
Digitalinput
0tomax30VDC
CongurableI/O1(Inputor
Output)
3
Digitaloutput(transistor–open
collector)
0tomax30VDC,opendrain,
100mA
Digitalinput
0tomax30VDC
CongurableI/O2(Inputor
Output)
5
Digitaloutput(transistor–open
collector)
0tomax30VDC,opendrain,
100mA
Networkconnectordipswitches
Important
Alwaysusethedefaultdipswitchsetting(positionB)iftherelationshipbetweendevicesinthesystemisnotdened.
ThecameraattachesaparticularVLANtagtoallitsforwardedmulticastpackages.Themediaconverterswitchmanageshowthese
multicastpackagesareforwardedbetweencameras,mediaconverterswitchesandothernetworkdevices.Thisisespeciallyuseful
whenconnectingthecameraandmediaconverterswitchtothenetworkinadaisychain.
Bychangingthepositionofthedipswitches,eachnetworkconnectorportinthemediaconverterswitchcanbecongured
tomanagemulticastsinthreedifferentways.
DipswitchpositionDescription
Default(middle)
BRemoveVLANtagsfromforwardedmulticastpackages.Usethissettingwhenconnectingtothe
network,directlyorthrougharouterornetworkswitch.
LeftABlockmulticastpackagesthathaveaVLANtag.Usethissettingwhenconnectingtoadevicethatis
notintendedformulticastviewing.
Right
C
ForwardmulticastpackageswithaVLANtag.Usethissettingwhenconnectingtoanothermedia
converterswitch.
VLANtagsareusedtocreateindependentlogicalnetworks,virtuallocalareanetworks(VLANs),withinaphysicalnetwork.Multiple
mediaconverterswitchesthatareconnectedtoeachotherinadaisychainaremembersofthesameVLAN.Themediaconverter
switchestagthemulticastpackagesmovingbetweenthemsothatthenextmediaconverterswitchinlineknowsthedestinationof
thepackages.Inotherwords,theVLANtagservesasaVLANidentier.VLANtaggingshouldonlybeusedwhenusingmultiple
camerasandmediaconverterswitchesbecauseforwardingmulticastpackageswithaVLANtagonlyservesapurposewhentheport
isconnectedtoanothermediaconverterswitch,whichmightbeconnectedtopotentialviewers.
