AXISQ60Series
ConnettoreI/O
Ingresso
alimentazioneCC
Ingresso
alimentazioneCA
Schemadelleconnessioni
ConnettoreI/O
1
0VCC(-)
2
UscitaCC3,3V,max250mA
A
I/Oconguratocomeingresso
98
