AXISQ86–ESeries
PowerConsumption
ProductInputVoltage
MaxConsumptionTypicalConsumption
24VAC
55W40W
120VAC
55W40W
AXIS
Q8631–E
AXIS
Q8632–E
230VAC
55W40W
InstalltheHardware
InstalltheBracket(soldseparately)
Thebracketsaresoldseparately.Seewww.axis.comforinformationonavailablemounting
accessories.
WARNING
Riskofinjury.Makesuretheproductissecuredtothebuildingsurfacebeforeoperation.
Important
•Whenattachingthebrackettoaconcretesurface,usedowelpinswithatractiontorque
ratingof≤300dN.
•Whenattachingthebrackettoametalsurface,usescrewswithadiameterof8mm.
1.Prepareawall,parapetorpoleforinstallingtheselectedbracket.
2.Routethenetworkandpowercablethroughthebracket.Leaveacableslackof
50cm(12in)forconnectiontothebaseunit.
