Axis Q86-E Series User Manual

AXISQ8632-EPTThermalNetworkCamera
AboutPTZ(PanTiltZoom)
ExtendedDriverSpecicSettings
ExtendedDriverSpecicSettingsforVideoSource1allowsyoutocongurethefollowingparameters:
MoveSpeed-Enteravaluefrom1–100andclickSavetosetthepan/tiltspeed.
NozzlePosition-SelectNozzlePositionandclickSavetosavethecurrentPTpositionasthewashingpositionandtoenablethe
washerbuttonontheLiveViewpage.ForinformationabouthowtocongurethewasherseeConguretheWasheronpage27
WasherConguration-Enteravalue(1or2)andclickSavetoselectawasherconguration.Formoredetailedinformationabout
thewashercongurations,seeConguretheWasheronpage27.
Lightsensorbox-SelectLightsensorboxandclickSavetoenabletheexternallightsensor.
Calibrate-SelectCalibrateandclickSavetoresetcamerapositionifthecameraorientationhasbeenchangedbyoutercircumstance.
ImageFreezeMode-SelectPresetstofreezethevideostreamwhilethecamerachangespresetposition.SelectAlltofreezethe
videostreamwhilethecamerachangespresetpositionorduringmanualpan/tiltoperation.SelectOfftodisableimagefreezemode.
AboutadvancedPTZsettings
AdvancedPTZsettingscanbeconguredunderPTZ>Advanced>Controls.
ThePanelShortcutCommandButtonslistshowstheuser-denedbuttonsthatcanbeaccessedfromtheLiveViewpage’sCtrl
panel.ThesebuttonscanbeusedtoprovidedirectaccesstocommandsissuedusingtheVAPIX®applicationprogramminginterface.
ClickAddtoaddanewshortcutcommandbutton.
ThefollowingPTZcontrolsareenabledbydefault:
•Pancontrol
•Tiltcontrol
Todisablespeciccontrols,deselecttheoptionsunderEnable/Disablecontrols.
Note
DisablingPTZcontrolswillnotaffectpresetpositions.Forexample,ifthetiltcontrolisdisabled,theproductcanstillmoveto
presetpositionsthatrequireatiltmovement.
ConguretheWasher
Theproductcanbeequippedwithanoptionalwasher(notincluded)toenablecleaningoftheprotectivewindow.
ToenablethewasherbuttonontheLiveviewpageandcongurethewasher:
1.GotoLiveView.
2.ClickSetemulatedjoystickmode,seeAboutthePTcontrolsonpage12.
3.Usethejoysticktopositionthewashernozzleinthecenteroftheliveviewimage.
4.GotoPTZ>Advanced>Device.
5.SelectNozzlePosition.
6.InWasherConguration,enteravalue(1or2)toselectthedesiredwasherconguration.TypicallyselectWasher
Conguration1ifthewasherliquidtankislocatedclosetothenozzle.SelectWasherConguration2ifthewasherliquid
tankislocatedfurtherawayfromthenozzle.Seethetablebelowformoredetailsaboutthewashercongurations.
7.ClickSave.
27
