Axis Q8685-E - Power Connector

AXISQ8685-EPTZNetworkCamera
1
DCground
2
DCoutput12V,max50mA
3
I/Oconguredasinput
4
I/Oconguredasoutput
5
CongurableI/O
6
CongurableI/O
Powerconnector
4-pinterminalblockforpowerinput.
24VAC/DCpowerconnector
NO NO
NO
TICE TICE
TICE
Thissectionisvalidforproductspoweredby24VACand24VDConly.
Thistableisonlyvalidforthe24VACandthe24VDCpowerconnectors.
Position
24VAC24VDC
1
ProtectiveearthProtectiveearth
2
24VACPhase
+24V
28
