Axis Q8685-E - Cables

AXISQ8685-EPTZNetworkCamera
Thistableisonlyvalidforthe24VACandthe24VDCpowerconnectors.(Continued)
Position
24VAC24VDC
3
24VACNeutral
0V
4
NotconnectedNotconnected
240VACpowerconnector
NO NO
NO
TICE TICE
TICE
Thissectionisvalidforproductspoweredby100–240VAConly.
Thistableisonlyvalidforthe240VACpowerconnector.
Position
100–240VAC
1
Protectiveearth
2
240VACNeutral
3
Notconnected
4
240VACPhase
Cables
Cablethickness
Thecablediameter,whenusingcablegasketsprovidedwiththeproduct,shouldbeintherangeof
5to11mm(0.2to0.4in).
