AXIS
Q87
Bispectral
PTZ
Network
Camera
Series
1.
Remove
the
four
base
unit
screws
(T30).
2.
Simultaneously
pull
and
turn
the
base
unit
counterclockwise
until
the
arrows
on
the
base
unit
and
the
rest
of
the
unit
are
aligned.
3.
Remove
the
base
unit.
NO
NO
NO
TICE
TICE
TICE
Do
not
use
sharp
tools
when
removing
the
transparent
base
unit
cover
.
4.
Remove
the
transparent
base
unit
cover
.
14
13
15
Table of Contents
Installation Guide
1
Safety Information
7
Hazard Levels
7
Other Message Levels
7
Safety Instructions
8
Package Contents
10
Hardware Overview
11
How to Install the Product
13
Mount the Base Unit
13
Route the Cables
15
Install the Network Link
21
Connect the Cables
22
How to Adjust the Weathershield
23
How to Access the Product
23
Reset to Factory Default Settings
24
Further Information
26
Optional Accessories
26
Warranty Information
26
Specifications
27
SD Card Slot
27
Network Connector
27
Power Connector
29
Cable Thickness
30
Operating Conditions
30
Power Consumption
30
