YP3040Pan-TiltMotor
AbouttheDIPSwitchSettings
Thetransmissionbetweenthemotorandthecamerawillnotworkifthecamerausesadifferent
protocolandbitratethanthemotor.ForcameraswithadifferentprotocolthanthePelco-Dandbit
rateof2400bps,thedipswitchesmustbechanged,seeChangetheDIPSwitchSettingsonpage12.
Note
ThedefaultfactorysettingsoftheYP3040Pan-TiltMotorarethePelco-Dprotocolanda
bitrateof2400bps.ThismeansthattheDIPswitchsettingsdonotneedtobechanged
whenusingthemotorwithanAxisnetworkcamerawiththePelco-Dprotocol.
TheYP3040Pan-TiltMotorhastwosetsof8digitalDIPswitches.
1
Selectadress
2
Selectfunction
The8switchesontheleft-handsideareusedtoselectfunctionssuchasprotocol,bitrate,and
terminalresistance.The8switchesontheright-handsideareusedtoselectmultipleunique
addresseswhenconnectingseveralunitsinaseriesthroughamulti-channelvideoserver.Thereare
255differentswitchcombinations.
Note
Inatypicalinstallationonlytheonedefaultaddressisrequired.
11
