Illustration and Parts Description
12
Blade tensioning knob
Upper door locking knob
Blade observation window
Lower door locking knob
Saw frame
Fence locking lever
NVR On/Off switch
Upper door wheel
Lower door wheel
Upper blade guide & guard
‘T’ slot for mitre fence
Stabilising bolt
Fence guide rail
Flexible extraction hose
Cast iron table
Upper blade guide
adjusting knob & clamp
Idler wheel adjusting knob
Fence
AC2606B Bandsaw
AC2305B Bandsaw
