Axminster AC1950B - Page 33

Parts Breakdown/List
33
No Description
1 Guide bracket
2 Motor
3 Lower wheel shaft
4 Upper wheel shaft
5 Upper wheel shaft seat
6 Sliding axle bracket
7 Upper wheel sliding axle
8 Spring
9 Strip washer
10 Adjusting nut
11 Adjusting knob
12 Door lock knob
13 Brush
14 Spacer bushing for brush
15 Cover clip
16 Setting knob
17 Lower guide seat
18 Wing nut
19 Bearing 80101
20 Step bolt M8X105
21 Hex.nut M6
22 Micro switch ass’y
23 Power switch
24 Saw blade
25 Upper wheel
26 Lower wheel
27 Upper guide housing
28 Connection seat,upper guide
29 Connection shaft,upper guide
30 Upper guide guard
31 Upper guide guard base
32 Rear thrust ceramic wheel
33 Side guide shaft
34 Guide shaft
35 Hex. socket pan head screw M4X12
36 Cover plate,upper guide guard
37 Sight glass
38 Protection board
39 Cross recessed pan head screw M4X6
40 Cross recessed pan head screw M4X30
41 Cross recessed pan head screw M3X25
42 Cross recessed pan head screw M5X8
43 Cross recessed pan head screw M4X10
44 Pointer bending plate
45 Pointer
46 Dishing cover
47 Spring
48 Adjusting gear wheel,upper guide
49 Adjusting knob,upper guide
50 Wing nut
51 Motor pulley
52 Adjusting rack,upper guide
53 Protection cover,lower guide
54 Saw frame
55 Micro switch ass’y
56 Upper door
57 Lower door
58 Hinge
59 Drive belt
60 Touching plate,micro switch
61 Washer 4
62 Hex.nut M4
63 Hex.nut M3
64 Hex.nut M6
65 Hex.nut M5
66 Hex.nut M14
67 Side extraction adaptor
68 Bottom extraction adaptor
69 Anti-loosening nut M6
70 Washer 3
71 Washer 6
72 Washer 8
73 Push stick hook
74 Hex. socket cap head bolt M5X20
75 Hex. socket cap head bolt M5X10
76 Hex. socket cap head bolt M4X16
77 Hex. socket cap head bolt M5X16
78 Hex. socket cap head bolt M6X12
79 Hex. socket cap head bolt M8X30
80 Pointer screw
81 Cross recessed socket screw M4X14
82 Cross recessed socket screw M3X6
83 Hex.bolt M6X20
84 Hex.bolt M6X16
85 Hex.bolt M6X12
86 Washer 5
87 Washer 8
88 Taping screw ST3.5X10
89 Taping screw ST3.5X13
90 Hex.socket set screw M6X6
91 Self-locking nut M5
92 Self-locking nut M8
93 Step bolt M6X65
94 Step bolt M8X70
95 Circlips for holes 28
96 Circlips for shafts 12
97 Spring washer 8
