Axminster AC1950B - Page 38

Parts Breakdown/List
38
Model AC1950B, AC2305B, AC2606B
No Description
1 Upper long bracket
2 Stand leg
3 Upper short bracket
4 Lower short bracket
5 Lower long bracket
6 Hex.socket pan head screw M6X16
7 Washer 8
8 Washer 6
9 Hex.nut M8
10 Hex.nut M6
11 Hex.bolt M6X35
12 Hex.bolt M8X30
13 Gasket nut
14 Rubber mat
15 Washer 8
16 Hex.nut M8
