Axminster AWVSL900 - Table of Contents; Index of Contents; Declaration of Conformity; Specification

02
WHITE
AXMINSTER
W
Table of Contents...
Specification...
Page No.
Index of Contents............................................................................................................................................ 2
Declaration of Conformity................................................................................................................................2
Specification.....................................................................................................................................................2
Declaration of Conformity....………………………………………………...........................................................2
General Safety Rules......................…………............................................................................................... 3-4
Specific Safety Rules for Wood Lathe........................................................................................ 5-6
Electrical Information...................................................................................................................6-7
Know your Wood Lathe..................................................................................................................8
Unpacking Contents..................................................................................................................9-10
Assembly................................................................................................................................. 11-12
Adjustments.................................................................................................................................. 13
Operation................................................................................................................................. 14-15
Maintenance..................................................................................................................................15
Parts Breakdown Part 1................................................................................................................16
Parts List Part 1.............................................................................................................................17
Parts Breakdown Part 2................................................................................................................18
Parts List Part 2.............................................................................................................................19
The undersigned, K. Ehret authorised by Shandong Laizhou Light
Industry Machinery Plant No. 989, North Lai Zhou Road
Laizhou,Shandong 261400 P.R. China
declares that this product:
Wood Lathe MC900
manufactured by Shandong Laizhou Light Industry Machinery
Plant is in compliance with the following standards or
standardisation documents in accordance with Council Directives,
EN 55 014:1993, EN 61000-3-3:1995, EN 55 014-2:1997
The undersigned, Cajus M. Dinies authorised
by Shandong Laizhou Light Industry Machinery Plant No. 989,
North Lai Zhou Road Laizhou,Shandong 261400 P.R. China
declares that this product:
Wood Lathe MC1100
manufactured by Shandong Laizhou Light Industry Machinery Plant
is in compliance with the following standards or standardisation
documents in accordance with Council Directives,
EN 55 014:1993, EN 61000-3-3:1995, EN 55 014-2:1997
Declaration of Conformity...
Copied from CE Certificate
Axminster No. AWVSL900 AWVSL1000
700205Part No: 700206
Rating:
Motor:
Speed:
Spindle Taper:
Spindle Thread:
Taper Tailstock:
Distance Between Centres:
Max Diameter Over Bed:
Tool Rest Stem Diameter:
Overall L x W x H:
Weight:
Hobby
240V 50Hz 550W
500-2000rpm
2MT
1" x 8tpi (Ref T04M)
2MT
840mm
280mm
25mm
1600 x 470 x 1120mm
72kg
Hobby
240V 50Hz 750W
500-2000rpm
2MT
1" x 8tpi (Ref T04M)
2MT
1100mm
350mm
25mm
1680 x 470 x 1155mm
97kg
