Axminster C0 - Specifications

3
SPECIFICATIONS
Max. swing over bed 100 mm
Max. length of workpiece 125 mm
Hole through spindle 10 mm
Hole through tailstock quill 10 mm
Spindle speed (Variable speed) 100-3800 rpm ±10%
Motor output power 150 W
Packing size 500x400x310 mm
Net/Gross weight 13 / 22 kgs
FEATURES
1 2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17
LEGEND
1. Cover 2. Headstock
3. Emergency Stop Switch 4. Variable speed control knob
5. Power light 6. Yellow light
7. Chuck cover 8. 3-jaw chuck
9. DC motor 10. Tool rest (optional)
11. Tailstock casting 12. Tailstock handlewheel
13. Handwheel 14. Base
15. handlewheel 16. Bedway
17. Leadscrew
