Parts List ( I )
Item Part name Qty. Item Part name Qty.
1 Bed way 1 51 Screw M5*20 2
2 Leadscrew left support 1 52 Small washer 5 2
3 Screw M6*14 10 53 Nut M5 2
4
Protective cover for
leadscrew
1
54
Motor connect plate 1
5 Screw M4*6 1 55 Washer 5 3
6 Screw ST2.9*6.5 3 56 Screw M5*14 3
7 Screw M3*8 4 57 key 3*16 1
8 PC Board 1 58 DC Motor 1
9 Electricity fixed plate 1 Mat plate 1
10 Screw M6*12 6 60 Screw ST2.9*9.5 4
11 Rubber pad 4 61 Electric box cover 1
12 Nut M6 6 62 Emergency stop button 1
13 Small washer 6 10 63 Variable speed control knob 1
14 Switch label 1 64 Yellow lamp 1
15 lock connect 2 65 Green lamp 1
16 Power line 1 66 Variable speed control 1
17 Base 1 67 Fuse box 1
18 Nut M4 5 68 plastic tube 1
19 Spring washer 4 7 69 Screw M4*8 2
20 Screw M4*10 3 70 protective cover for chuck 1
21 leadscrew 1 71 Rotate shaft 1
22 Leadscrew right support 1 72 key 3*6 1
23 Handle wheel 3 73 Spacer 1
24 Cap nut M5 3 74 Compress spring L=16 1
25 Rotate small handle 3 75 Screw M2*20 2
26 Handle screw 3 76 Micro switch 1
27 Screw M4*6 9 77 Nut M2 2
28 Flat washer 4 4 78 Electric box 1
29 Dust guard 1 79 Knife rest 1
30 3 jaw chuck 1 80 Screw M4*6 1
31 Spindle 1 81 Screw M6*35 1
32 Bearing 17*35*10 2 82 Tailstock shaft 1
33 check ring 35 2 83 Screw M6*16 1
34 Screw M6*40 3 84 Set screw 1
35 Fixed support 1 85 Set screw M6*8 1
36 Screw M4*8 2 86 Tailstock shaft leadscrew 1
37 Check ring 17 1 87 Small handle 2
38 V pulley 1 88 Nesting 1
39 Adjust ring 1 89 baffle 1
40 Washer 1 90 Tailstock 1
41 Headstock 1 91 Screw M5*8 1
42 Pulley cover 1 92 Screw M4*16 2
43 Nut M4 4 93 Saddle nut 1
44 Washer 4 4 94 Leadscrew 1
45 Screw M4*8 6 95 Saddle nut 1
46 Higne 38*31 2 97 Small washer 4 4
47 Check ring 8 2 98 Screw M4*10 4
48 V belt 1 99 Nut support 1
49 V pulley 1 100 Bolt M4*10 4
50 Spring washer 6 4 101 Washer 4 2
