ASSEMBLY
11
Fig 18-19-20
Guide assembly bolt
Wheel brush
7) Repeat steps 3 and 4 on page 10 for setting the thrust
bearing and blade guides, see figs 21-22-23-24.
Fig 21-22-23-24
Continues over...
B
