ILLUSTRATION AND PARTS DESCRIPTION
15
Upper saw wheel
Upper wheel tracking and tensioning assemblyMicro switch
Micro switch
Lower saw wheel
Drive belt
Bandsaw blade
Wheel brush
Drive pulleyTensioning idler wheel
(AW2305B, AW2606B ONLY)
Continues over...
