Axon MICRELEC CS2600 User Manual

5
1 Specifications
1-1 Technical specifications
Dimensions
Height × Width × Depth：90 mm × 62.8 mm × 153 mm
Weight
132 g, without cable
Cable
Straight 2.0 m
Connector Type
RJ-45 phone jack connector
Case Material
PC+TPU
Exit Window
Material
Tempered glass
Indicator
Beeper, LED
Interface Supported
RS-232, USB Keyboard, USB virtual COM
Operating Mode
Hand-held, Auto-detection
Programming
Method
Manual (reading special barcode)
Firmware Upgrade
Online
Input Voltage
5 ± 0.25 VDC
Current
Standby: 160 mA , Scanning: 300 mA (Max:480 mA)
Image Size
1280 × 800 pixels
Light Source
Illumination : 5000 K , white LED
Aiming: 525 nm peak wavelength, green LED
Imager Field of View
Horizontal: 41°, vertical: 28°
Scanning Angle
±70°, ±75°, 360° (skew, pitch, roll)
Print Contrast
20% minimum reflective difference
Decoding Capability
1D: UPC-A, UPC-E, UPC-E1, EAN-13, EAN-8, ISBN (Bookland EAN), ISSN, Code 39, Code
39 full ASCII, Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5 (Discrete 2 of 5),
Matrix 2 of 5, Codabar (NW7), Code 128, UCC/EAN 128, ISBT 128, Code 93, Code 11
(USD-8), MSI/Plessey, UK/Plessey, China Post, GS1 DataBar (formerly RSS) variants
2D: PDF417, QR Code, DataMatrix, Han Xin Code, Aztec Code, MicroQR Code, MicroPDF417
Minimum Resolution
HD：1D（Code 39）： 3mil
SR：1D（Code 128）： 4mil
Decoding Depth
High Density Series Standard Range Series
3 mil Code39 (3 chars)
25 mm – 50 mm /
4 mil Code39 (9 chars)
10 mm – 90 mm 30 mm – 90 mm
5 mil Code39 (3 chars)
5 mm – 115 mm 20 mm – 120 mm
13 mil UPC (6 chars)
0 mm – 250 mm 0 mm – 280 mm
20 mil Code39 (1 char)
15 mm – 340 mm 15 mm – 430 mm
6.7 mil PDF417 (20 chars)
10 mm – 100 mm 15 mm – 120 mm
10 mil QR (20 chars)
0 mm – 155 mm 0 mm – 165 mm
10 mil DM (20 chars)
0 mm – 160 mm 0 mm – 165 mm
20 mil QR (20 chars)
0 mm – 270 mm 0 mm – 340 mm
Temperature
-10° to 50°C (14° to 122°F), operating; -20° to 70°C (-4° to 158°F), storage
Humidity
5% to 95% (non-condensing)
Safety
Photobiological Safety: EN62471
EMC: EN55032, EN55024
RF Immunity: IEC61000-4-3, 10 V/m
Immunity: 0~100,000 lux
Sealing: IP52
Drop Resistance: Withstands multiple 2.0 m drops to concrete
