Axpert KING 3KVA - Page 26

SERVICE MANUAL
3KVA/5KVA-230V
26
V201703A
Remove the screws,
and then you can
take the main board
out.
Note: There are ten
screws to fix the main
board.
Note: When you put the new control board on the main board, please make sure that the connection is
correct and tighten. Don’t forget to put the screws and cables back.
